Rope, Water Rescue
Prices and Availability of All Items Are Subject to Change Without Notice




Water Rescue Throwline (4500 lb. Strength)

Our most popular and highly recommended double braid water rescue throwline featuring a recently developed multifilament polypropylene fiber core that has twice the tensile strength of standard multifilament polypropylene yarn. The tightly braided sheath of premium quality DuPont nylon provides abrasion resistance plus adds to the overall strength. This combination produces a strong, floating, flexible, highly visible yet economical rope. This is the rope used in our #4570 Water Rescue Throw Bags found on page 152. DO NOT USE FOR RAPPELLING OR RESCUE SYSTEMS. Diameter: 3/8”(10mm). Tensile strength: 4500 lbs.(2041kg). Colors: bright yellow with orange strikers standard, yellow with blue strikers and solid yellow are optional.

Catalog #45XX Water Rescue Throwline (4500 lb.) (replace XX with desired length)

Water Rescue Throwline (5000 lb. Strength)

This kernmantle rope combines the unique properties of two different fibers to produce a line with the best features of each. A nylon jacket makes for greater strength and increased abrasion resistance, while the multifilament polypropylene core allows the rope to float. Excellent as a water rescue throwline. DO NOT USE FOR RAPPELLING OR RESCUE SYSTEMS. Diameter: 7/16”(11mm). Tensile strength: 5000 lbs.(2268kg). Color: bright yellow.

Catalog #50XX Water Rescue Throwline (5000 lb.) (replace XX with desired length)

Water Rescue Throwline (1800 lb. Strength)

A soft, pliable 100% polypropylene solid braid floating line. Available in a host of solid colors and stripes. Good hand, easy to work with, resistant to rot, abrasion, and grease. An economical solution to water rescue throwlines. This is the rope used in our #1870 and #1850 Water Rescue Throw Bags found on page 152. DO NOT USE FOR RAPPELLING OR RESCUE SYSTEMS. Diameter: 3/8”(10mm). Tensile strength: 1800 lbs.(816kg). Colors: white & red striped, other colors available upon special order.

Catalog #18XX Water Rescue Throwline (1800 lb.) (replace XX with desired length)

PMI

Water Rescue Rope‑Kernmantle

Construction is of the kernmantle design: The continuous stranded core is made of multifilament polypropylene which provides the buoyancy to float the braided nylon sheath. The sheath is the same nylon braid that makes PMI ropes number one in abrasion resistance. PMI WATER RESCUE ROPES SHOULD NOT BE USED FOR RAPPELLING OR TO LIFT CRITICAL LIVE LOADS.

CONSTRUCTION: Kernmantle

MATERIAL: Sheath DuPont 707 type 6,6 nylon; core Phillips multifilament polypropylene.

ELONGATION (stretch): Greater than 50% at failure.

HEAT RESISTANCE: Core melts at 235F.(113C).  Sheath melts at 480F.(249C).

BRAID: one over one under for high abrasion resistance

CORE: Continuous, spliceless parallel fiber bundles.

IDENTIFICATION: Continuous marker in core.

LENGTH: Any length from 1 foot to over one mile.

COLOR: Sheath bright yellow with blue stripe. Core off white.

Size

Weight/100’(30.5m)

Minimum Strength

1/4”(6.4mm)

3.9 lbs.(1.8kg)

1900 lbs.(862kg)

3/8”(10mm)

4.8 lbs.(2.2kg)

3600 lbs.(1633kg)

1/2”(12.5mm)

6.3 lbs.(2.9kg)

5000 lbs.(2268kg)



Catalog #1107720 1/4”(6.4mm) Water Rescue Rope

Catalog #1112720 3/8”(10mm) Water Rescue Rope

Catalog #1116720 1/2”(12.5mm) Water Rescue Rope

PMI

VIS-MAT™ High Visibility Water Rescue Rope

VIS-MAT™ uses yarns made with 3M Scotchlite™ reflective material braided directly into the sheath. Thus, the rope can be seen clearly even in pitch-black conditions when a light is shined on it. Fluorescent yarn in the sheath also provides high visibility during daytime and low light conditions. Color: Yellow sheath with blue and reflective tracer.

Size

Weight/100’(30.5m)

Minimum Strength

3/8”(10mm)

4.8 lbs.(2.2kg)

3600 lbs.(1633kg)



Catalog #1112V20 3/8”(10mm) VIS-MAT™ Water Rescue Rope



Sterling Rope Company

5/16” Waterline

5/16" Waterlines feature bright yellow polypropylene sheath for high visibility and nylon core for strength

  • MBS of 1600 lbs
  • The supple nature of these high floatation ropes make for easy stuffing and quicker deployment during rescues
  • Ideal for use in throw bags and as swimmer tether lines



Elongation at 300 lbs

7.80%

MBS lbs (kN)

1,600 (7.1)

Weight (lbs/100')

2.1





3/8” Waterline

3/8" Waterlines feature bright yellow polypropylene sheath for high visibility and nylon DryCore for strength and minimum moisture absorption.

  • The supple nature of these high floatation ropes make for easy stuffing and quicker deployment during rescues
  • Ideal for use in throw bags, as swimmer tether lines and "tag lines"
  • Certified to NFPA 1983, 2006 edition - Throwlines



A NFPA1983,2006 certified product

Yes

Elongation at 300 lbs

4.00%

MBS lbs (kN)

3,440 (15.3)

Weight (lbs/100')

3.3





7/16” Waterline

Features a double-braided high tenacity polypropylene construction for high strength, great handling and maximum floatation

  • MBS of 4450 lbs
  • Provides better abrasion resistance and a larger diameter for a better grip with a gloved hand
  • Ideal choice for ice rescue due to its higher strength and supple hand



Elongation at 300 lbs

2.50%

MBS lbs (kN)

4,450 (19.8)

Weight (lbs/100')

4.3





Grabline



Grabline is Sterling Rope's high tensile strength Waterline with a "grip-able", tread-like sheath. These ropes also feature a nylon core, which provides strength without sacrificing its supple nature.



5/16” Grabline



  • MBS of 1600 lbs
  • Typical throwlines are slippery, Grabline solves this problem with its unique tread-like sheath construction.
  • Better hand traction makes it easier to grab, hold, and throw



Elongation at 300 lbs

8.00%

MBS lbs (kN)

1,600 (7.1)

Weight (lbs/100')

2.1





3/8” Grabline



  • Certified to NFPA 1983, 2006 edition - Throwlines
  • MBS of 1600 lbs
  • Typical throwlines are slippery, Grabline solves this problem with its unique tread-like sheath construction.
  • Better hand traction makes it easier to grab, hold, and throw.



A NFPA1983,2006 certified product

Yes

Elongation at 300 lbs

3.75%

MBS lbs (kN)

3,282 (14.6)

Weight (lbs/100')

3.1





3/8” Grabline Glo

Grabline SafetyGlo has same features as the standard Grabline but also has a highly reflective strip braided into the sheath.

  • This provides additional visibility for night and low light rescues
  • Certified to NFPA 1983, 2006 edition – Throwlines



A NFPA1983,2006 certified product

Yes

Elongation at 300 lbs

3.75%

MBS lbs (kN)

3,282 (14.6)

Weight (lbs/100')

3.1





Swiftwater Response



The Swiftwater Response is a 10mm high visibilty, high strength water rescue line. It features a nylon sheath with a polypropylene core.

  • MBS of 4000 lbs
  • Nylon sheath offers greater abrasion resistance and high durablity
  • High tenacity multi-filament braided polypropylene core for maximum floatation.
  • Supple enough for use in throwbags and strong enough for use in river rescue haul system or boat lines.



Elongation at 300 lbs

2.80%

MBS lbs (kN)

4,000 (17.8)

Weight (lbs/100')

3.5





1/4” Ultraline

Features a high strength braided Dyneema core and a polypropylene sheath

  • MBS of 2608 lbs
  • Superior strength, is easy to handle and deploy, and floats.
  • Perfect for rescue swimmer tether lines, life ring lines, and other high strength applications.



Elongation at 300 lbs

2.00%

MBS lbs (kN)

2,608 (11.6)

Weight (lbs/100')

1.3





3/8” Ultraline

Features a high strength braided Dyneema core and a polypropylene sheath

  • MBS of 5261 lbs
  • Superior strength, is easy to handle and deploy, and floats
  • Perfect for z-drags and other high strength applications
  • Certified to NFPA 1983, 2006 edition for Throwlines



A NFPA1983,2006 certified product

Yes

Elongation at 300 lbs

1.40%

MBS lbs (kN)

5,261 (23.4)

Weight (lbs/100')

3.8









Pidgeon Mountain Industries



PMI Water Rescue Throw Rope

This rope is intended for use as a bagged throw rope for boat or shore based rescue. The polypropylene core provides floatation, while the nylon sheath gives this line superior abrasion resistance.



PMI Water Rescue Throw Rope 7mm



PMI Water Rescue Throw Rope 10mm (Also Avaliable With Retro Reflective Strip)





New England Ropes



MFP Throwline 3/8”

12-Strand hollow braid of 100% high tenacity polypropylene that flakes easily, resists kinking, and floats indefinitely.

Features:

·         Spliceable

·         Bright yellow cover aids in visibility

  • Floats Indefinitely

Applications:

  • Water Rescue Throwline
  • Heaving Line
  • River Raft Lanyards

Sunlight/UV:
Very little degradation from sunlight. Can be used outside over long term if inspected regularly.

Chemicals:
Polypropylene has excellent resistance to most acids and alkalines, except chlorosulphonic, concentrated sulfuric acids, and chlorinated hydrocarbons at 160°F. Polypropylene also withstands most diluted bleaching solutions.

Heat:
Polypropylene melts at 330°F with progressive strength loss above 200°F.

Dielectrics:
Good resistance to the passage of electrical current. However, dirt, surface contaminants, water entrapment, and the like can significantly affect dielectric properties. Extreme caution should be exercised any time a rope is in the proximity of live circuits.

MFP Throwline 5/16”

12-Strand hollow braid of 100% high tenacity polypropylene that flakes easily, resists kinking, and floats indefinitely.

Features:

  • Spliceable
  • Bright yellow cover aids in visibility
  • Floats Indefinitely

Applications:

  • Water Rescue Throwline
  • Heaving Line
  • River Raft Lanyards

Sunlight/UV:
Very little degradation from sunlight. Can be used outside over long term if inspected regularly.

Chemicals:
Polypropylene has excellent resistance to most acids and alkalines, except chlorosulphonic, concentrated sulfuric acids, and chlorinated hydrocarbons at 160°F. Polypropylene also withstands most diluted bleaching solutions.

Heat:
Polypropylene melts at 330°F with progressive strength loss above 200°F.

Dielectrics:
Good resistance to the passage of electrical current. However, dirt, surface contaminants, water entrapment, and the like can significantly affect dielectric properties. Extreme caution should be exercised any time a rope is in the proximity of live circuits.

NFPA Rescue Rope

First NFPA and UL Certified water rescue throwline on the market. Designed to meet the new NFPA 1983:2006 specifications. Double braided construction is flexible and durable. Polyester cover, Dyneema Core

Features:

  • Spliceable
  • Bright yellow cover aids in visibility
  • Floats indefinitely
  • Dyneema Core for high strength

Applications:

  • Water Rescue Throwline

Sunlight/UV:
Very little degradation from sunlight. Can be used outside over long term if inspected regularly.

Chemicals:
HMPE has good resistance to most minerals, organics, acids, and weak alkalines. HMPE also has excellent resistance to bleaches and other oxidizing agents and to most solvents. Polypropylene has excellent resistance to most acids and alkalines, except chlorosulphonic, concentrated sulfuric acids, and chlorinated hydrocarbons at 160°F. Polypropylene also withstands most diluted bleaching solutions.

Heat:
HMPE melts at 300°F with progressive strength loss above 150°F. Polypropylene melts at 330°F with progressive strength loss above 200°F.

Dielectrics:
Good resistance to the passage of electrical current. However, dirt, surface contaminants, water entrapment, and the like can significantly affect dielectric properties. Extreme caution should be exercised any time a rope is in the proximity of live circuits.

Water Rescue Rope

This Water Rescue Rope is a unique rescue system lifeline contructed from durable nylon in the cover and spliceable MFP in the core.

Features:

  • Spliceable
  • Bright yellow cover aids in visibility

Applications:

  • Rescue lifeline
  • Any application involving Prusiks, Gibbs, and Belay devices
  • Water Rescue Throwline
  • Heaving Line
  • River Raft Lanyards

Sunlight/UV:
Very little degradation from sunlight. Can be used outside over long term if inspected regularly.

Chemicals:
Nylon will degrade with strong oxidizing agents, mineral acids, and 90% formic acid. May discolor when exposed to high levels of carbon dioxide. Polypropylene has excellent resistance to most acids and alkalines, except chlorosulphonic, concentrated sulfuric acids, and chlorinated hydrocarbons at 160°F. Polypropylene also withstands most diluted bleaching solutions.

Heat:
Nylon melts at 460°F with progressive strength loss above 300°F. Polypropylene melts at 330°F with progressive strength loss above 200°F.

Dielectrics:
Good resistance to the passage of electrical current. However, dirt, surface contaminants, water entrapment, and the like can significantly affect dielectric properties. Extreme caution should be exercised any time a rope is in the proximity of live circuits.
